• Pure sine wave output
• Self-consumption and deed in to the grid
• Programmable supply priority for PV, Battery or Grid
• User-adjustable battery charging current suits different types of batteries
• Programmable multiple operation modes: Grid-tie,Off-grid and grid-tie with backup
• Built-in timer for various mode of on/off operation
• Multiple communication for USB.RS232,Modbus and SNMP
• Monitoring software for rel-time status display and control
• Parallel operation up to 6 units for 10KW
• Pure sine wave output
• Self-consumption and deed in to the grid
• Programmable supply priority for PV, Battery or Grid
• User-adjustable battery charging current suits different types of batteries
• Programmable multiple operation modes: Grid-tie,Off-grid and grid-tie with backup
• Built-in timer for various mode of on/off operation
• Multiple communication for USB.RS232,Modbus and SNMP
• Monitoring software for rel-time status display and control
• Parallel operation up to 6 units for 10KW
Tags：
Technical Specifications:
Model | WTX5532 |
PHASE | 1-phase in/1 phase out |
Max. PV INPUT POWER | 6500W |
Rated Output Power | 5500W |
Maximum Charging Power | 2880 W |
GRID TIE OPERATION | |
PV INPUT (DC) | |
Nominal DC Voltage/Max. DC Voltage | 360 VDC/500 VDC |
Start-up Voltage/lnitial Feeding Voltage | 116 VDC/150 VDC |
MPP Voltage Range | 120 VDC-450 VDC |
Number of MPP Trackers | 2/2x13A |
Maximum Input Current | 2/2x13A |
GRID OUTPUT (AC) | |
Nominal Output Voltage | 208/220/230/240 VAC |
Output Voltage Range | 184-265 VAC* |
Nominal Output Current | 23.9A |
Power Factor | > 0.99 |
EFFICIENCY | |
Maximum Conversion Efficiency (DC/AC) | 96% |
European Efficiency@Vnominal | 95% |
OFF GRID OPERATION | |
AC INPUT | |
AC start-up Voltage | 120-140 VAC/180 VAC |
Auto Restart Voltage | 120-140 VAC/180 VAC |
Acceptable Input Voltage Range | 170-280 VAC |
Max. AC Input Current | 40A |
PV INPUT (DC) | |
Max. DC Voltage | 500 VDC |
MPP Voltage Range | 120 VDC-450 VDC |
Number of MPPTrackers/Max. Input Current | 2/2x13A |
BATTERY Mode Output (AC) | |
Nominal Output Voltage | 202/208/220/230/240 VAC |
Output Waveform | Pure Sine Wave |
Efficiency (DC to AC) | 93% |
HYBRID OPER/EON | |
PV INPUT (DC) | |
Nominal DC Voltage/Max. DC Voltage | 360 VDC/500 VDC |
Start-up Voltage/lnitial Feeding Voltage | 116 VDC/150 VDC |
MPP Voltage Range | 120 VDC-450 VDC |
Number of MPP Trackers/Max. Input Current | 2/2x13A |
GRID OUTOUT (AC) | |
Nominal Output Voltage | 202/208/220/230/240 VAC |
Output Voltage Range | 184-264.5 VAC* |
Nominal Output Current | 23.9A |
AC INPUT | |
AC Start-up Voltage/Auto Restart Voltage | 120-140 VAC/180 VAC |
Acceptable Input Voltage Range | 170-280 VAC |
Max. AC Input Current | 30A |
BATTERY MODE OUTPUT (AC) | |
Nominal Output Voltage | 202/208/220/230/240 VAC |
Efficiency (DC to AC) | 93% |
BATTERY& CHARGER | |
Battery DC Voltage | 48V |
Max. Charging Current | Default 60A |
GENERAL | |
PHYSICAL | |
Dimension, DxWxH (mm) | 110*450*445 |
Net weight (kgs) | 16 |
INTERFACE | |
Communication Port | RS-232/USB and CAN Interface |
ENVIRONMENT | |
Humidity | 0 -90%RH |
Operating Temperature | 0to40℃ |
Altitude | 0-1000 m** |
